Core Data

Position Mid Motor Wheel Diameter (Inch) Optional Construction Gear drive Rated Voltage (DCV) 36/48 n0 (Rpm) 83/87 Rated Power (W) 250 nT(Rpm) 78/83 Max Torque 80 N.m Efficiency (%) ≥ 80 Pedal Sensor Speed Shaft Standard JIS Color Black Weight (kg) 3.8 Noise Grade (dB) < 55 Operating Temperature -20-45℃

Function

E-Brake Yes Gearsensor Function Yes Light Drive Capacity (DCV / W) 6 /3(max)

Further Specifications

Speed Detection Signal (Pulses/Cycle) 1 Reduction Ratio 1:21.9 Magnet Poles (2P) 16
